Alien Hydroponics V-System 18 Pot Deep Water Culture System

Alien Hydroponics V-System DWC - 18 Pot

Sale Price:

~~Translation missing: en.product.price.range_html~~ Translation missing: en.product.price.range_htmlTranslation missing: en.product.price.range_html

Pay as little as
$579045/mo

for a term that suits you, up to 36 months.

🍃 Earn 5,791 points for shopping and get $57.90 off your next order. Join Harvest Club for free

Free shipping over $50
We price match!
Thousands of 5-Star Reviews
Inquire for bulk pricing
Expert help +1 (360) 800-5535
Chat with our team

Alien Hydroponics V-System 18 Pot Features

Venturi Valve Technology

The V-System deep water culture kit uses Venturi Valve Technology to ensure healthier root zones by optimizing oxygenation.

Temperature Control

Reduce root rot chances with the built-in temperature control of the V-Sys hydroponic kit.

Modular Design

When you’re ready to expand your system, you can customize the layout up to four rows with ten pots in each row for optimal distribution in each pot.

Equal Nutrient Distribution

The V-System hydroponic kit ensures equal nutrient distribution so all plants grow healthy.

Alien Hydroponics V-System 18 Pot Highlights

15 gallon (58L) V-POT
18 V-Pots
Three rows
1100-watt Jet-Stream Vortex pump - 3 Row
1500-watt Jet-Stream Vortex pump - 2 Row
Total-drainage bases
Venturi injectors
Five-inch spiral tubing
Five-inch Dual-Flow fittings
Integrated filtration
T304 Stainless clamps
Push-fit feed connections
Expandable up to four rows, ten pots per row

What is Included in the Alien Hydroponics V-System 18 Pot?

▼2 Row Configuration

V-SYSTEM Vortex Water Pump 1500W 240V 22500 l/h
V-Pot 58L
V-Pot Base
V-Pot Lid
V-Pot Lid Inspection Cover
Square Net Pot
V-Pot Clip
Air Filter for V-SYSTEM Venturi, 6mm
Silencer for Venturi
Venturi Fitting
Venturi Air Inlet Pipe 6mm Blue (2X 4")
Nut 5"
Washer 5" Green Silicone
5" Stainless Steel Clamp
Distribution Tee 50mm
DM Push-Fit Elbow 28mm V-SYSTEM
DM Push-Fit Tee 28-15mm V-SYSTEM
1/2" Drain Cap Fitting
Drain Tap 1/2"-16mm Barb
Elbow 5" Barbed with Drain Point
Elbow 5" Threaded Dual-Flow
Filter Manifold Complete 50mm-2"
Float Valve
V-SYSTEM Header Pot 20L 50mm
Silver Lid
Header Pot Blank
Hosetail 16mm-3/4" Female Green
Venturi Inlet Fitting for 28mm Pipe
Pipe 28mm White Rigid 1 Meter - Venturi Feed
Pipe 50mm Silver 1 Meter
Pipe 5" Silver Spiral 80cm
Tee 5" Barbed
Tee Threaded 5" Dual-Flow
Threaded Tank Connector 1"
Vortex Pump Inlet Manifold 50mm
1" Cap for Chiller Connections
50mm Straight Dual Flow Fitting
Elbow 50mm Barbed
Terminal Manifold Left 50mm
Terminal Manifold Right 50mm
28mm Insert for 28mm Rigid Pipe
28mm Push-Fit Stop End
Clamp Size 4
8mm Screwdriver for 5" Clamp
Wrench 5"
Wrench for Float Valve
8mm Socket for 5" Clamp
Pipe Cutter 50mm
Silicone Grease - Food Grade

◄3 Row Configuration

1x V-SYSTEM Vortex Water Pump 370W 120V 13200 l/h
18x V-Pot 58L
18x V-Pot Base
18x V-Pot Lid
18x V-Pot Lid Inspection Cover
18x Square Net Pot
18x V-Pot Clip
18x Air Filter for V-SYSTEM Venturi, 6mm
18x Silencer for Venturi
18x Venturi Fitting
18x Venturi Air Inlet Pipe 6mm Blue (2X 4")
18x Venturi Inlet Fitting for 22mm Pipe
19x Nut 5"
19x Washer 5" Green Silicone
44x 5" Stainless Steel Clamp
1x Dis22tribution Tee 40mm
3x DM Push-Fit Elbow 22-15mm V-SYSTEM
3x DM Push-Fit Elbow 22mm V-SYSTEM
15x DM Push-Fit Tee 22-15mm V-SYSTEM
1x Drain Cap 1/2"
1x Drain Tap 1/2"-16mm Barb
2x Elbow 5" Barbed with Drain Point
4x Elbow 5" Threaded Dual-Flow
1x Filter Manifold, Complete 40mm
1x Float Valve
1x V-SYSTEM Header Pot 20L 40mm
1x Silver Lid
1x Header Pot Blank
1x Hosetail 16mm-3/4" Female Green
18x Pipe 22mm Rigid 1 Meter - Venturi Feed
1x Pipe 32mm Red 1 Meter Spiral
4x Pipe 40mm Silver 1 Meter Spiral
19x Pipe 5" Spiral 80cm
1x Tee 5" Barbed
15x Tee Threaded 5" Dual-Flow
2x Threaded Tank Connector 1"
1x Vortex Pump Inlet Manifold40mm long
2x 1" Cap for Chiller Connections
1x T/Connector Straight 32mm
1x T/Connector Straight 40mm
1x Terminal Manifold Left
1x Terminal Manifold Right
20x 22mm Insert for 22mm Rigid Pipe
2x Clamp Size 2
42x Clamp Size 3
1x 8mm Screwdriver for 5" Clamp
1x Wrench 5"
1x Wrench for Float Valve
1x 8mm Socket for 5" Clamp
1x Pipe Cutter 50mm
5x Silicone Grease - Food Grade

Alien Hydroponics V-System 18 Pot Specifications

▼2 Row Configuration

Number of pots:	18
Number of rows:	2
Kit total fluid volume:	296.1 gallons (1121 L)
Minimum assembled size (can space pots more widely for a larger footprint):
Length:	17' 9.8" (213.8 inches / 5430 mm)
Width:	3' 11.2" (47.2 inches / 1200 mm)
Water Pump Included with the Kit:
Model:	V-SYSTEM Vortex Water Pump 1500W 240V 22500 l/h
Wattage:	1500 watts
Flow Rate:	5944 gal/hr (22500 L/hr)
Recommended water chiller minimum capacity:	528 gallons (2000 L)

◄3 Row Cofiguration

Number of pots:	18
Number of rows:	3
Kit total fluid volume:	293.8 gallons (1112 L)
Minimum assembled size (can space pots more widely for a larger footprint):
Length:	12' 1.3" (145.3 inches / 3690 mm)
Width:	5' 9.3" (69.3 inches / 1760 mm)
Water Pump Included with the Kit:
Model:	V-SYSTEM Vortex Water Pump 1100W 120V 17700 l/h
Wattage:	1100 watts
Flow Rate:	4676 gal/hr (17700 L/hr)
Recommended water chiller minimum capacity:	528 gallons (2000 L)

Alien Hydroponics V-System 18 Pot Manual

Alien Hydroponics V-System 18 Pot Instruction Manual

Alien Hydroponics V-System 18 Pot Technical Drawing

Alien Hydroponics V-System 18 Warranty

Alien Hydroponics provides a 3-year warranty for all parts and a standard 1-year warranty for pumps.
